# Implement MPEG-Dash using Transloadit

The demo below encodes a video file into two high-quality, video-only versions as well as into two high-quality, audio-only versions in order to prepare the video file for use with MPEG-Dash.

The demo then pushes all these result files into [🤖/video/adaptive](/docs/robots/video-adaptive.md), which cuts them into several segments, before generating the MPEG-Dash segments and the manifest file. Lastly, all the files are stored in your Amazon S3 bucket. The trick here is that all files are already stored in the proper location to make sure that the manifest file works. This is done using the special `"${file.meta.relative_path}"` variable.

[🤖/video/adaptive](/docs/robots/video-adaptive.md) also supports HTTP Live Streaming (HLS). For more information about that, please check [its docs](/docs/robots/video-adaptive.md).

Step 1

### Handle uploads

We can handle uploads of your users directly. [Learn more ›](/services/handling-uploads.md)

[kite25.mp4](https://demos.transloadit.com/dashtest/kite25.mp4)

Video · 4.3 MB · 27s · 1024 × 768

```
":original": {
  "robot": "/upload/handle"
}
```

🤖 [/upload/handle](/docs/robots/upload-handle.md)

This bot receives uploads that your users throw at you from browser or apps, or that you throw at us programmatically

Step 2

### Transcode, resize, or watermark videos

We offer a variety of video encoding features like optimizing for different devices, merging, injecting ads, changing audio tracks, or adding company logos. [Learn more ›](/services/video-encoding.md)

[1d0ff2f98783401d85ae3483aebd3ee7.mp4](https://tmp-eu-west-1.transloadit.net/4ce4fb3d9d1842b6ba5d6f3ccee4b066/27ba80cfdaa74fa99e4222037674fb0c/1d0ff2f98783401d85ae3483aebd3ee7.mp4)

Video · 1.5 MB · 27s · 480 × 270

```
"p270_video": {
  "use": ":original",
  "robot": "/video/encode",
  "result": true,
  "ffmpeg_stack": "v7",
  "preset": "dash-270p-video",
  "turbo": false
}
```

🤖 [/video/encode](/docs/robots/video-encode.md)

This bot encodes, resizes, applies watermarks to videos and animated GIFs

Step 3

### Transcode, resize, or watermark videos

We offer a variety of video encoding features like optimizing for different devices, merging, injecting ads, changing audio tracks, or adding company logos. [Learn more ›](/services/video-encoding.md)

[9a408f8c270743c4a5dfaf7bad3a8f6a.mp4](https://tmp-eu-west-1.transloadit.net/4ce4fb3d9d1842b6ba5d6f3ccee4b066/27ba80cfdaa74fa99e4222037674fb0c/9a408f8c270743c4a5dfaf7bad3a8f6a.mp4)

Video · 2.6 MB · 27s · 640 × 360

```
"p360_video": {
  "use": ":original",
  "robot": "/video/encode",
  "result": true,
  "ffmpeg_stack": "v7",
  "preset": "dash-360p-video",
  "turbo": false
}
```

🤖 [/video/encode](/docs/robots/video-encode.md)

This bot encodes, resizes, applies watermarks to videos and animated GIFs

Step 4

### Transcode, resize, or watermark videos

We offer a variety of video encoding features like optimizing for different devices, merging, injecting ads, changing audio tracks, or adding company logos. [Learn more ›](/services/video-encoding.md)

[beec16c93fb6427182c396af8c294264.mp4](https://tmp-eu-west-1.transloadit.net/4ce4fb3d9d1842b6ba5d6f3ccee4b066/27ba80cfdaa74fa99e4222037674fb0c/beec16c93fb6427182c396af8c294264.mp4)

Audio · 112 KB · 27s

```
"b32k_audio": {
  "use": ":original",
  "robot": "/video/encode",
  "result": true,
  "ffmpeg_stack": "v7",
  "preset": "dash-32k_audio",
  "turbo": false
}
```

🤖 [/video/encode](/docs/robots/video-encode.md)

This bot encodes, resizes, applies watermarks to videos and animated GIFs

Step 5

### Transcode, resize, or watermark videos

We offer a variety of video encoding features like optimizing for different devices, merging, injecting ads, changing audio tracks, or adding company logos. [Learn more ›](/services/video-encoding.md)

[a68ee51cc35a461a94e7c754fb5b88d0.mp4](https://tmp-eu-west-1.transloadit.net/4ce4fb3d9d1842b6ba5d6f3ccee4b066/27ba80cfdaa74fa99e4222037674fb0c/a68ee51cc35a461a94e7c754fb5b88d0.mp4)

Audio · 218 KB · 27s

```
"b64k_audio": {
  "use": ":original",
  "robot": "/video/encode",
  "result": true,
  "ffmpeg_stack": "v7",
  "preset": "dash-64k_audio",
  "turbo": false
}
```

🤖 [/video/encode](/docs/robots/video-encode.md)

This bot encodes, resizes, applies watermarks to videos and animated GIFs

Step 6

### Convert videos to HLS, MPEG-Dash and CMAF

We offer a variety of video encoding features like optimizing for different devices, merging, injecting ads, changing audio tracks, or adding company logos. [Learn more ›](/services/video-encoding.md)

[my\_playlist.mpd](https://demos.transloadit.com/dashtest/my%5Fplaylist.mpd)

Video · 2.3 KB · 27s · 480 × 270

[32377\_44100\_dashinit.mp4](https://demos.transloadit.com/dashtest/audio/32377%5F44100%5Fdashinit.mp4)

Audio · 113 KB · 27s · 480 × 270

[64270\_44100\_dashinit.mp4](https://demos.transloadit.com/dashtest/audio/64270%5F44100%5Fdashinit.mp4)

Audio · 219 KB · 27s · 480 × 270

[640x360\_817285\_30\_dashinit.mp4](https://demos.transloadit.com/dashtest/video/640x360%5F817285%5F30%5Fdashinit.mp4)

Video · 2.6 MB · 27s · 640 × 360

[480x270\_471923\_30\_dashinit.mp4](https://demos.transloadit.com/dashtest/video/480x270%5F471923%5F30%5Fdashinit.mp4)

Video · 1.5 MB · 27s · 480 × 270

```
"adaptive": {
  "use": {
    "steps": [
      "p270_video",
      "p360_video",
      "b32k_audio",
      "b64k_audio"
    ],
    "bundle_steps": true
  },
  "robot": "/video/adaptive",
  "playlist_name": "my_playlist.mpd",
  "technique": "dash"
}
```

🤖 [/video/adaptive](/docs/robots/video-adaptive.md)

This bot encodes videos into HTTP Live Streaming (HLS), MPEG-Dash and CMAF supported formats and generates the necessary manifest and playlist files

Step 7

### Export files to Amazon S3

We export to the storage platform of your choice. [Learn more ›](/services/file-exporting.md)

`:original`

* [https://demos.transloadit.com/dashtest/kite25.mp4⁠](https://demos.transloadit.com/dashtest/kite25.mp4)

`p270_video`

* [https://tmp-eu-west-1.transloadit.net/4ce4fb3d9d1842b6ba5d6f3ccee4b066/27ba80cfdaa74fa99e4222037674fb0c/1d0ff2f98783401d85ae3483aebd3ee7.mp4⁠](https://tmp-eu-west-1.transloadit.net/4ce4fb3d9d1842b6ba5d6f3ccee4b066/27ba80cfdaa74fa99e4222037674fb0c/1d0ff2f98783401d85ae3483aebd3ee7.mp4)

`p360_video`

* [https://tmp-eu-west-1.transloadit.net/4ce4fb3d9d1842b6ba5d6f3ccee4b066/27ba80cfdaa74fa99e4222037674fb0c/9a408f8c270743c4a5dfaf7bad3a8f6a.mp4⁠](https://tmp-eu-west-1.transloadit.net/4ce4fb3d9d1842b6ba5d6f3ccee4b066/27ba80cfdaa74fa99e4222037674fb0c/9a408f8c270743c4a5dfaf7bad3a8f6a.mp4)

`b32k_audio`

* [https://tmp-eu-west-1.transloadit.net/4ce4fb3d9d1842b6ba5d6f3ccee4b066/27ba80cfdaa74fa99e4222037674fb0c/beec16c93fb6427182c396af8c294264.mp4⁠](https://tmp-eu-west-1.transloadit.net/4ce4fb3d9d1842b6ba5d6f3ccee4b066/27ba80cfdaa74fa99e4222037674fb0c/beec16c93fb6427182c396af8c294264.mp4)

`b64k_audio`

* [https://tmp-eu-west-1.transloadit.net/4ce4fb3d9d1842b6ba5d6f3ccee4b066/27ba80cfdaa74fa99e4222037674fb0c/a68ee51cc35a461a94e7c754fb5b88d0.mp4⁠](https://tmp-eu-west-1.transloadit.net/4ce4fb3d9d1842b6ba5d6f3ccee4b066/27ba80cfdaa74fa99e4222037674fb0c/a68ee51cc35a461a94e7c754fb5b88d0.mp4)

`adaptive`

* [https://demos.transloadit.com/dashtest/my\_playlist.mpd⁠](https://demos.transloadit.com/dashtest/my%5Fplaylist.mpd)
* [https://demos.transloadit.com/dashtest/audio/32377\_44100\_dashinit.mp4⁠](https://demos.transloadit.com/dashtest/audio/32377%5F44100%5Fdashinit.mp4)
* [https://demos.transloadit.com/dashtest/audio/64270\_44100\_dashinit.mp4⁠](https://demos.transloadit.com/dashtest/audio/64270%5F44100%5Fdashinit.mp4)
* [https://demos.transloadit.com/dashtest/video/640x360\_817285\_30\_dashinit.mp4⁠](https://demos.transloadit.com/dashtest/video/640x360%5F817285%5F30%5Fdashinit.mp4)
* [https://demos.transloadit.com/dashtest/video/480x270\_471923\_30\_dashinit.mp4⁠](https://demos.transloadit.com/dashtest/video/480x270%5F471923%5F30%5Fdashinit.mp4)

```
"exported": {
  "use": [
    ":original",
    "adaptive"
  ],
  "robot": "/s3/store",
  "credentials": "demo_s3_credentials",
  "path": "dashtest/${file.meta.relative_path}/${file.name}",
  "url_prefix": "https://demos.transloadit.com/"
}
```

🤖 [/s3/store](/docs/robots/s3-store.md)

This bot exports encoding results to Amazon S3

## Live Demo. See for yourself

Loading Uppy demo…

This live demo is powered by [Uppy⁠](https://uppy.io/docs/guides/uppy-transloadit/), our open source file uploader that you can also use without Transloadit, and [tus⁠](https://tus.io), our open protocol for resumable file uploads that is making uploading more reliable across the world.

## Build this in your own language

```
<!-- This pulls Uppy from our CDN -->
<!-- For smaller self-hosted bundles, install Uppy and plugins manually: -->
<!-- npm i --save @uppy/core @uppy/dashboard @uppy/remote-sources @uppy/transloadit ... -->
<link
  href="https://releases.transloadit.com/uppy/v3.10.0/uppy.min.css"
  rel="stylesheet"
/>
<button id="browse">Select Files</button>
<script type="module">
  import {
    Uppy,
    Dashboard,
    ImageEditor,
    RemoteSources,
    Transloadit,
  } from 'https://releases.transloadit.com/uppy/v3.10.0/uppy.min.mjs'
  const uppy = new Uppy()
    .use(Transloadit, {
      waitForEncoding: true,
      alwaysRunAssembly: true,
      assemblyOptions: {
        params: {
          // It's often better store encoding instructions in your account
          // and use a `template_id` instead of adding these steps inline
          steps: {
            ':original': {
              robot: '/upload/handle',
            },
            p270_video: {
              use: ':original',
              robot: '/video/encode',
              result: true,
              ffmpeg_stack: 'v7',
              preset: 'dash-270p-video',
              turbo: false,
            },
            p360_video: {
              use: ':original',
              robot: '/video/encode',
              result: true,
              ffmpeg_stack: 'v7',
              preset: 'dash-360p-video',
              turbo: false,
            },
            b32k_audio: {
              use: ':original',
              robot: '/video/encode',
              result: true,
              ffmpeg_stack: 'v7',
              preset: 'dash-32k_audio',
              turbo: false,
            },
            b64k_audio: {
              use: ':original',
              robot: '/video/encode',
              result: true,
              ffmpeg_stack: 'v7',
              preset: 'dash-64k_audio',
              turbo: false,
            },
            adaptive: {
              use: {
                steps: ['p270_video', 'p360_video', 'b32k_audio', 'b64k_audio'],
                bundle_steps: true,
              },
              robot: '/video/adaptive',
              playlist_name: 'my_playlist.mpd',
              technique: 'dash',
            },
            exported: {
              use: [':original', 'adaptive'],
              robot: '/s3/store',
              credentials: 'demo_s3_credentials',
              path: 'dashtest/${file.meta.relative_path}/${file.name}',
              url_prefix: 'https://demos.transloadit.com/',
            },
          },
        },
      },
    })
    .use(Dashboard, { trigger: '#browse' })
    .use(ImageEditor, { target: Dashboard })
    .use(RemoteSources, {
      companionUrl: 'https://api2.transloadit.com/companion',
    })
    .on('complete', ({ transloadit }) => {
      // Due to `waitForEncoding:true` this is fired after encoding is done.
      // Alternatively, set `waitForEncoding` to `false` and provide a `notify_url`
      console.log(transloadit) // Array of Assembly Statuses
      for (const assembly of transloadit) {
        console.log(assembly.results) // Array of all encoding results
      }
    })
    .on('error', (error) => {
      console.error(error)
    })
</script>

```

[Read docs: Browsers](/docs/sdks/uppy.md)
