Concatenate audio

Usage example

{
  "steps": {
    "concatenated": {
      "robot": "/audio/concat",
      "use": {
        "steps": [
          {
            "name": ":original",
            "fields": "first_audio_file",
            "as": "audio_1"
          },
          {
            "name": ":original",
            "fields": "second_audio_file",
            "as": "audio_2"
          },
          {
            "name": ":original",
            "fields": "third_audio_file",
            "as": "audio_3"
          }
        ]
      },
      "ffmpeg_stack": "v6"
    }
  }
}

Parameters

• output_meta

  Record<string, boolean> | boolean | Array<string>

  Allows you to specify a set of metadata that is more expensive on CPU power to calculate, and thus is disabled by default to keep your Assemblies processing fast.

  For images, you can add "has_transparency": true in this object to extract if the image contains transparent parts and "dominant_colors": true to extract an array of hexadecimal color codes from the image.

  For videos, you can add the "colorspace: true" parameter to extract the colorspace of the output video.

  For audio, you can add "mean_volume": true to get a single value representing the mean average volume of the audio file.

  You can also set this to false to skip metadata extraction and speed up transcoding.

• result

  boolean

  Whether the results of this Step should be present in the Assembly Status JSON

• queue

  batch

  Setting the queue to 'batch', manually downgrades the priority of jobs for this step to avoid consuming Priority job slots for jobs that don't need zero queue waiting times

• force_accept

  boolean (default: false)

  Force a Robot to accept a file type it would have ignored.

  By default, Robots ignore files they are not familiar with. 🤖/video/encode, for example, will happily ignore input images.

  With the force_accept parameter set to true, you can force Robots to accept all files thrown at them. This will typically lead to errors and should only be used for debugging or combatting edge cases.

• use

  string | Array<string> | Array<object> | object

  Specifies which Step(s) to use as input.

  • You can pick any names for Steps except ":original" (reserved for user uploads handled by Transloadit)
  • You can provide several Steps as input with arrays:


    {
      "use": [
        ":original",
        "encoded",
        "resized"
      ]
    }


  Tip

  That's likely all you need to know about use, but you can view Advanced use cases.

• ffmpeg

  object

  A parameter object to be passed to FFmpeg. If a preset is used, the options specified are merged on top of the ones from the preset. For available options, see the FFmpeg documentation. Options specified here take precedence over the preset options.

• ffmpeg_stack

  v5 | v6 | v7 | string (default: "v5.0.0")

  Selects the FFmpeg stack version to use for encoding. These versions reflect real FFmpeg versions. We currently recommend to use "v6.0.0".

• preset

  aac | alac | audio/aac | audio/alac | audio/flac | audio/mp3 | audio/ogg | 35 more ↓

  Performs conversion using pre-configured settings.

  If you specify your own FFmpeg parameters using the Robot's ffmpeg parameter and you have not specified a preset, then the default mp3 preset is not applied. This is to prevent you from having to override each of the MP3 preset's values manually.

  For a list of audio presets, see audio presets.

• bitrate

  string | number

  Bit rate of the resulting audio file, in bits per second. If not specified will default to the bit rate of the input audio file.

• sample_rate

  string | number

  Sample rate of the resulting audio file, in Hertz. If not specified will default to the sample rate of the input audio file.

• audio_fade_seconds

  string | number (default: 1)

  When used this adds an audio fade in and out effect between each section of your concatenated audio file. The float value is used, so if you want an audio delay effect of 500 milliseconds between each video section, you would select 0.5. Integer values can also be represented.

  This parameter does not add an audio fade effect at the beginning or end of your result audio file. If you want to do so, create an additional 🤖/audio/encode Step and use our ffmpeg parameter as shown in this demo.

• crossfade

  boolean (default: false)

  When set to true, this parameter enables crossfading between concatenated audio files using FFmpeg's acrossfade filter. This creates a smooth transition where the end of one audio file overlaps and blends with the beginning of the next file.

  The duration of the crossfade is controlled by the audio_fade_seconds parameter (defaults to 1 second if audio_fade_seconds is 0).

  Note: This parameter requires at least 2 audio files to concatenate and only works with audio files, not video files.
