Export files to Google Storage

Usage example

{
  "steps": {
    "exported": {
      "robot": "/google/store",
      "use": ":original",
      "credentials": "YOUR_GOOGLE_CREDENTIALS",
      "path": "my_target_folder/${unique_prefix}/${file.url_name}"
    }
  }
}

Parameters

• interpolate

  boolean | Record<string, boolean>

  Controls whether Assembly Variables are interpolated for individual instruction fields.

  By default, most Robot instruction fields interpolate Assembly Variables. Set this to false to treat every instruction field as literal text, or set an individual field path to false to treat only that field as literal text. For Robot-specific fields that are literal by default, set this to true or set that field path to true to opt back into interpolation.

  Use field names such as path, or dotted paths such as ffmpeg.vf for nested objects.

• output_meta

  Record<string, boolean> | boolean | Array<string>

  Allows you to specify a set of metadata that is more expensive on CPU power to calculate, and thus is disabled by default to keep your Assemblies processing fast.

  For images, you can add "has_transparency": true in this object to extract if the image contains transparent parts and "dominant_colors": true to extract an array of hexadecimal color codes from the image.

  For images, you can also add "blurhash": true to extract a BlurHash string — a compact representation of a placeholder for the image, useful for showing a blurred preview while the full image loads.

  For videos, you can add the "colorspace: true" parameter to extract the colorspace of the output video.

  For videos, you can also add "interlaced": true to detect whether the video is interlaced. This combines the cheap ffprobe field_order flag with a bounded idet sampling pass over the first frames of the source, exposing interlaced, field_order, and a diagnostic interlace_detection object under file.meta. This is computationally expensive and billed accordingly.

  For audio, you can add "mean_volume": true to get a single value representing the mean average volume of the audio file.

  You can also set this to false to skip metadata extraction and speed up transcoding.

• result

  boolean

  Whether the results of this Step should be present in the Assembly Status JSON

• queue

  batch

  Setting the queue to 'batch', manually downgrades the priority of jobs for this step to avoid consuming Priority job slots for jobs that don't need zero queue waiting times

• force_accept

  boolean (default: false)

  Force a Robot to accept a file type it would have ignored.

  By default, Robots ignore files they are not familiar with. 🤖/video/encode, for example, will happily ignore input images.

  With the force_accept parameter set to true, you can force Robots to accept all files thrown at them. This will typically lead to errors and should only be used for debugging or combatting edge cases.

• ignore_errors

  boolean | Array<meta | execute> (default: [])

  Ignore errors during specific phases of processing.

  Setting this to ["meta"] will cause the Robot to ignore errors during metadata extraction.

  Setting this to ["execute"] will cause the Robot to ignore errors during the main execution phase.

  Setting this to true is equivalent to ["meta", "execute"] and will ignore errors in both phases.

• use

  string | Array<string> | Array<object> | object

  Specifies which Step(s) to use as input.

  • You can pick any names for Steps except ":original" (reserved for user uploads handled by Transloadit)
  • You can provide several Steps as input with arrays:


    {
      "use": [
        ":original",
        "encoded",
        "resized"
      ]
    }


  • You can also tag an input Step with as to pass semantic intent to robots:
  • You can also tag input Steps with as to pass semantic intent to robots:


    {
      "use": [
        {
          "name": ":original",
          "as": "image"
        },
        {
          "name": ":original",
          "as": "mask"
        }
      ]
    }


  Tip

  That's likely all you need to know about use, but you can view Advanced use cases.

• credentials — required

  string

  Create a new Google service account. Set its role to "Storage Object Creator". Choose "JSON" for the key file format and download it to your computer. You will need to upload this file when creating your Template Credentials.

  Go back to your Google credentials project and enable the "Google Cloud Storage JSON API" for it. Wait around ten minutes for the action to propagate through the Google network. Grab the project ID from the dropdown menu in the header bar on the Google site. You will also need it later on.

  Now you can set up the storage.objects.create and storage.objects.delete permissions. The latter is optional and only required if you intend to overwrite existing paths.

  To do this from the Google Cloud console, navigate to "IAM & Admin" and select "Roles". From here, click "Create Role", enter a name, set the role launch stage to General availability, and set the permissions stated above.

  Next, go to Storage browser and select the ellipsis on your bucket to edit bucket permissions. From here, select "Add Member", enter your service account as a new member, and select your newly created role.

  Then, create your associated Template Credentials in your Transloadit account and use the name of your Template Credentials as this parameter's value.

• path

  string (default: "${unique_prefix}/${file.url_name}")

  The path at which the file is to be stored. This may include any available Assembly Variables.

• acl

  authenticated-read | bucket-owner-full-control | private | project-private | public-read | null (default: "public-read")

  The permissions used for this file.

• cache_control

  string

  The Cache-Control header determines how long browsers are allowed to cache your object for. Values specified with this parameter will be added to the object's metadata under the Cache-Control header. For more information on valid values, take a look at the official Google documentation.

• url_template

  string (default: "https://{HOST}/{PATH}")

  The URL of the file in the result JSON. This may include any of the following supported Assembly variables.

• ssl_url_template

  string (default: "https://{HOST}/{PATH}")

  The SSL URL of the file in the result JSON. The following Assembly variables are supported.
