Optimize images without quality loss

Usage example

{
  "steps": {
    "optimized": {
      "robot": "/image/optimize",
      "use": ":original"
    }
  }
}

Parameters

• interpolate

  boolean | Record<string, boolean>

  Controls whether Assembly Variables are interpolated for individual instruction fields.

  By default, most Robot instruction fields interpolate Assembly Variables. Set this to false to treat every instruction field as literal text, or set an individual field path to false to treat only that field as literal text. For Robot-specific fields that are literal by default, set this to true or set that field path to true to opt back into interpolation.

  Use field names such as path, or dotted paths such as ffmpeg.vf for nested objects.

• output_meta

  Record<string, boolean> | boolean | Array<string>

  Allows you to specify a set of metadata that is more expensive on CPU power to calculate, and thus is disabled by default to keep your Assemblies processing fast.

  For images, you can add "has_transparency": true in this object to extract if the image contains transparent parts and "dominant_colors": true to extract an array of hexadecimal color codes from the image.

  For images, you can also add "blurhash": true to extract a BlurHash string — a compact representation of a placeholder for the image, useful for showing a blurred preview while the full image loads.

  For videos, you can add the "colorspace: true" parameter to extract the colorspace of the output video.

  For videos, you can also add "interlaced": true to detect whether the video is interlaced. This combines the cheap ffprobe field_order flag with a bounded idet sampling pass over the first frames of the source, exposing interlaced, field_order, and a diagnostic interlace_detection object under file.meta. This is computationally expensive and billed accordingly.

  For audio, you can add "mean_volume": true to get a single value representing the mean average volume of the audio file.

  You can also set this to false to skip metadata extraction and speed up transcoding.

• result

  boolean (default: false)

  Whether the results of this Step should be present in the Assembly Status JSON

• queue

  batch

  Setting the queue to 'batch', manually downgrades the priority of jobs for this step to avoid consuming Priority job slots for jobs that don't need zero queue waiting times

• force_accept

  boolean (default: false)

  Force a Robot to accept a file type it would have ignored.

  By default, Robots ignore files they are not familiar with. 🤖/video/encode, for example, will happily ignore input images.

  With the force_accept parameter set to true, you can force Robots to accept all files thrown at them. This will typically lead to errors and should only be used for debugging or combatting edge cases.

• ignore_errors

  boolean | Array<meta | execute> (default: [])

  Ignore errors during specific phases of processing.

  Setting this to ["meta"] will cause the Robot to ignore errors during metadata extraction.

  Setting this to ["execute"] will cause the Robot to ignore errors during the main execution phase.

  Setting this to true is equivalent to ["meta", "execute"] and will ignore errors in both phases.

• use

  string | Array<string> | Array<object> | object

  Specifies which Step(s) to use as input.

  • You can pick any names for Steps except ":original" (reserved for user uploads handled by Transloadit)
  • You can provide several Steps as input with arrays:


    {
      "use": [
        ":original",
        "encoded",
        "resized"
      ]
    }


  • You can also tag an input Step with as to pass semantic intent to robots:
  • You can also tag input Steps with as to pass semantic intent to robots:


    {
      "use": [
        {
          "name": ":original",
          "as": "image"
        },
        {
          "name": ":original",
          "as": "mask"
        }
      ]
    }


  Tip

  That's likely all you need to know about use, but you can view Advanced use cases.

• priority

  compression-ratio | conversion-speed (default: "conversion-speed")

  Provides different algorithms for better or worse compression for your images, but that run slower or faster. The value "conversion-speed" will result in an average compression ratio of 18%. "compression-ratio" will result in an average compression ratio of 31%.

• progressive

  boolean (default: false)

  Interlaces the image if set to true, which makes the result image load progressively in browsers. Instead of rendering the image from top to bottom, the browser will first show a low-res blurry version of the image which is then quickly replaced with the actual image as the data arrives. This greatly increases the user experience, but comes at a loss of about 10% of the file size reduction.

• preserve_meta_data

  boolean (default: true)

  Specifies if the image's metadata should be preserved during the optimization, or not. If it is not preserved, the file size is even further reduced. But be aware that this could strip a photographer's copyright information, which for obvious reasons can be frowned upon.

• fix_breaking_images

  boolean (default: true)

  If set to true this parameter tries to fix images that would otherwise make the underlying tool error out and thereby break your Assemblies. This can sometimes result in a larger file size, though.

• lossy

  boolean (default: false)

  When set to false (the default), only lossless PNG optimizers are used, disabling pngquant to preserve color accuracy.

  When set to true, both lossy and lossless PNG optimizers compete and the smallest result wins. This allows pngquant, a lossy compressor that reduces PNGs to a 256-color palette, which may cause noticeable color shifts in images with rich color palettes, subtle gradients, or brand-specific colors.

  Note

  This parameter only affects PNG optimization. JPEG, GIF, WebP, and SVG optimization is unaffected.
