`/image/resize` robot

Takes a single image file as input and produces a resized version of it. Ideal for generating thumbnails.

Optional parameters

Name	Type	Default	Description
width	`1 - 5000`	Width of the input image	Size for the new image in px
height	`1 - 5000`	Height of the input image	Height for the new image in px
strip	boolean	`false`	Strips all meta data from the image. Ideal for thumbnails where you want to save every byte.
flatten	boolean	`true`	Flattens all layers onto your chosen background for a better result from transparent formats to non-transparent formats. Detailed explanation: Layers . Important: Gif files are not flattened even with a parameter value of `true`. This is to preserve their animation by default. If you'd like to flatten gif animations, please use the `frame` parameter.
correct_gamma	boolean	`false`	Works around a flaw that is present in most image scaling algorithms. For more information see this article: Gamma error in picture scaling
quality	`1 - 100`	Quality of the input image or `92`	Control the image compression for jpg and png images.
background	string	`"#FFFFFF"`	Either a hex code or the name of a color to fill the background with (only used for the pad resize strategy).
resize_strategy	string	`"fit"`	See list of resize strategies.
zoom	boolean	`true`	If set to false it forces smaller images to not be stretched to the desired width and height. See the list of resize strategies to see which special impact zoom has on your preferred resize strategy.
crop	`{ x1: integer, y1: integer, x2: integer, y2: integer }`	`{}`	Specify an object that contains the coordinates of the top left and the bottom right corner of a rectangle that should be cropped from the original image(s). An example value is `{x1: 80, y1: 100, x2: 160, y2: 180}` which would crop an area from `(80;100)` to `(160;180)` which has a width and height of both 80px. If `crop` is set, any width and height parameters are ignored and the `resize_strategy` is set to `crop` automatically.
format	string	`Format of the input image`	Available formats: `"jpg"`, `"png"`, `"gif"`, `"tiff"`
frame	integer	`null` (all frames)	If you are dealing with animated gif files, you can use this parameter to specify which frame of the gif to use for the operation. Using `1` would select the first frame, `2` the second and so on.
colorspace	string	`""`	Set the image colorspace. Check this image magic documentation for available values.
rotation	string / boolean / integer	`true`	Determine if the image should be rotated. If you want images to be auto-rotated if they are miss-rotated or depend on Exif rotation then set this to `true`. You can also set this to an integer value to specify the rotation degrees. Additionally, you can optionally use `degrees>` if you want to rotate only if the image's width exceeds its height (`degrees<` if the width must be less than the height). Set the value to `false` to disable auto-fixing of miss-rotated images.

Watermark parameters

Name	Type	Default	Description
watermark_url	string	`""`	Url to a png image to overlay over this image.
watermark_position	string/array	`"center"`	The position you'd like the watermark to have. Available options are: `"center", "top", "bottom", "left", "right"`. You can also combine options, for example `"bottom-right"`. You can also specify an array of possible values out of which one value will be picked randomly. E.g. `["center","left","bottom-left","bottom-right"]` Note that this will push the watermark into the respective corner. If you want a specific pixel-offset on the watermark you need to include this in the form of padding into the image itself.
watermark_size	string	`""`	The size in percent for this watermark. E.g. a value of `"50%"` means that the watermark would be 50% of the size of the image it is put on.
watermark_resize_strategy	string	`"fit"`	Supports `"fit"` and `"stretch"`.

Resize Strategies

The examples below show the following image resized to 100x100px for each available strategy:

straw apple

Strategy	Description
fit	Uses width and height as the maximum values for the resize and preserves aspect ratio.
stretch	Ignores aspect ratio and resizes the image to the exact width and height given. This may result in a stretched / distorted image.
crop	Centers the image within the specified crop frame and discards any overlapping parts. If the source image is smaller than the crop frame, it gets zoomed. If crop coordinates are provided via the "crop" parameter, the specified image part according to the coordinates is cut from the original and no centering is taking place. Note: This strategy is not available for the video robots yet.
pad	Scales the image to fit and then fills the remaining width and height area with the defined background color (here #aa0000). If you use zoom: false with this strategy, then smaller images will be centered both horizontally and vertically and have the background pad around them.
