Introducing the new PDF merge Robot at Transloadit

Joseph Grabski

Content Lead · Rochester, United Kingdom · Show bio

We love our Robots, so it's always a pleasure to announce the release of a new one! In today's blog, we get the opportunity to do just that, by welcoming our /document/merge Robot to the team.

As you may have already assumed, the /document/merge Robot concatenates several PDFs, to form a single output document. Moreover, the Robot supports merging several password-protected PDFs – simply supply it with an array of input passwords. You can protect the output PDF as well, by providing an output password. Password protection is one part of a secure workflow, not a replacement for access control over your uploads, storage, and shared links.

Merging two PDFs

Let's see it in action! The below Template will take two password-protected PDFs and merge them together. You may also be interested in using one of our SDKs, to automate the bulk processing of documents.

<!-- This pulls Uppy from our CDN -->
<!-- For smaller self-hosted bundles, install Uppy and plugins manually: -->
<!-- npm i --save @uppy/core @uppy/dashboard @uppy/remote-sources @uppy/transloadit ... -->
<link
  href="https://releases.transloadit.com/uppy/v3.10.0/uppy.min.css"
  rel="stylesheet"
/>
<button id="browse">Select Files</button>
<script type="module">
  import {
    Uppy,
    Dashboard,
    ImageEditor,
    RemoteSources,
    Transloadit,
  } from 'https://releases.transloadit.com/uppy/v3.10.0/uppy.min.mjs'
  const uppy = new Uppy()
    .use(Transloadit, {
      waitForEncoding: true,
      alwaysRunAssembly: true,
      assemblyOptions: {
        params: {
          // It's often better store encoding instructions in your account
          // and use a `template_id` instead of adding these steps inline
          steps: {
            ':original': {
              robot: '/upload/handle',
            },
            merge: {
              use: {
                steps: [':original'],
                bundle_steps: true,
              },
              robot: '/document/merge',
              result: true,
              input_passwords: ['password1', 'password2'],
            },
            exported: {
              use: ['merge', ':original'],
              robot: '/s3/store',
              credentials: 'demo_s3_credentials',
              url_prefix: 'https://demos.transloadit.com/',
            },
          },
        },
      },
    })
    .use(Dashboard, { trigger: '#browse' })
    .use(ImageEditor, { target: Dashboard })
    .use(RemoteSources, {
      companionUrl: 'https://api2.transloadit.com/companion',
    })
    .on('complete', ({ transloadit }) => {
      // Due to `waitForEncoding:true` this is fired after encoding is done.
      // Alternatively, set `waitForEncoding` to `false` and provide a `notify_url`
      console.log(transloadit) // Array of Assembly Statuses
      for (const assembly of transloadit) {
        console.log(assembly.results) // Array of all encoding results
      }
    })
    .on('error', (error) => {
      console.error(error)
    })
</script>

This public demo uses sample documents and simple demonstration passwords. It exports both the originals and the unencrypted merged PDF to a public bucket. Use only non-sensitive files here; the private-storage example below is for your own integration.

As you can see, by passing in an array of passwords to the input_passwords parameter, Transloadit processes the PDFs. The documents are then stitched together into a single output PDF, which is shown below.

To password-protect the output, set output_password. Replace the password placeholders below on your trusted backend, using a strong, unique output password. Without explicit ordering, input files are sorted alphanumerically by filename: provide input_passwords in that same order, or use the document ordering options.

Create stored Template Credentials for your private S3 bucket and replace YOUR_AWS_CREDENTIALS with their name. This example exports only the encrypted merged PDF. bucket-default avoids requesting a public object ACL; the bucket policy must also remain private. The path below stays under the setup guide's uploads/ policy prefix; update the policy and path together if you change that prefix. Keep passwords out of browser code, public repositories, and logs.

{
  "steps": {
    "merge": {
      "use": {
        "steps": [":original"],
        "bundle_steps": true
      },
      "robot": "/document/merge",
      "input_passwords": ["FIRST_INPUT_PASSWORD", "SECOND_INPUT_PASSWORD"],
      "output_password": "REPLACE_WITH_A_STRONG_UNIQUE_PASSWORD",
      "result": true
    },
    "exported": {
      "use": "merge",
      "robot": "/s3/store",
      "credentials": "YOUR_AWS_CREDENTIALS",
      "acl": "bucket-default",
      "path": "uploads/merged/${unique_prefix}/${file.url_name}"
    }
  }
}

The output password applies to the merged PDF, not to the uploaded originals or every copy of the data. Restrict access to both inputs and results, and share the output password separately from the document. A weak or exposed password does not provide meaningful protection.

Wrapping up

That's it for today's look at our latest Robot. We've got a few more that are ready to be introduced, so stay tuned for future updates on all things Transloadit by signing up for the Dev Times below.
