Overlay videos with dynamic artwork, generated with HTML & JS

Transloadit customer HEROFI uses our service to dynamically generate artwork and then 'burn' it into videos, in order to create unique and customized content for their customers.

HEROFI's use case illustrates how powerful our building blocks can be when you add a little bit of creativity. HEROFI was gracious enough to let us showcase a sample of how they're watermarking user uploads for display in Buffalo Wild Wings restaurants.

While HEROFI performs a lot more magic in the form of slowdowns and concatenation, this demo will focus exclusively on the HTML-generated watermark case.

It all starts with an S3-hosted HTML file:

<!doctype html>
<html lang="en">
  <head>
    <meta charset="UTF-8">
  </head>

  <body style="background: transparent">
    <script>
      var logo_url = new URLSearchParams(window.location.search).get('logo_url')
      var store_name = new URLSearchParams(window.location.search).get('store_name')
      var label = new URLSearchParams(window.location.search).get('label')

      var watermarking = [
        {
          type: 'image',
          src: logo_url,
          css: {
            position: 'absolute',
            left: '60px',
            bottom: '90px',
            'max-width': '200px',
            'max-height': '100px',
          },
        },
        {
          type: 'storetext',
          metatag: 'x-amz-meta-storename',
          text: store_name,
          css: {
            position: 'absolute',
            left: '60px',
            bottom: '60px',
            background: '#ffd200',
            padding: '4px',
            color: '#fff',
            width: '200px',
            'text-align': 'center',
          },
        },
        {
          type: 'cliptext',
          metatag: 'x-amz-meta-cliptitle',
          text: label,
          css: {
            position: 'absolute',
            right: '0',
            bottom: '60px',
            background: 'rgba(0,0,0,.1)',
            padding: '20px',
            color: '#fff',
            'font-size': '48px',
          },
        },
      ]

      function getStyle(obj) {
        var style = ''
        for (var key in obj) {
          style += key + ':' + obj[key] + ';'
        }
        return style
      }

      if (watermarking && watermarking.length) {
        for (var i = 0; i < watermarking.length; i++) {
          switch (watermarking[i].type) {
            case 'image':
              var div = document.createElement('div')
              div.innerHTML =
                '<img style="' +
                getStyle(watermarking[i].css) +
                '" src="' +
                watermarking[i].src +
                '" />'
              document.getElementsByTagName('body')[0].appendChild(div)
              break
            case 'storetext':
              var div = document.createElement('div')
              div.innerText = watermarking[i].text
              div.style = getStyle(watermarking[i].css)
              document.getElementsByTagName('body')[0].appendChild(div)
              break
            case 'cliptext':
              var div = document.createElement('div')
              div.innerText = watermarking[i].text
              div.style = getStyle(watermarking[i].css)
              document.getElementsByTagName('body')[0].appendChild(div)
              break
          }
        }
      }
    </script>
  </body>
</html>

As you can see, the file takes query parameters and uses JavaScript to dynamically create labels along those parameters. In addition, it takes the URL-encoded location of a logo.

Transloadit sources an input video (in this demo you can upload one, but we can just as easily import from a cloud location), we then take a PNG screenshot of the HTML file with labels and a logo passed in through the query parameters, before using that screenshot to create a video overlay.

These Assembly Instructions make it easy to generate custom videos for specific restaurants, days, or events — just by changing the logo_url, store_name, and label query parameters.

Let's take a look at all the Steps involved.

⚠️ It seems your browser does not send the referer, which we need to stop people from (ab)using our demos in other websites. If you want to use the demos, please allow your browser to send its referer to us. Adding us to the allowlist of blockers usually helps.

Step 1: Handle uploads

We can handle uploads of your users directly. Learn more ›

⚠️ It seems your browser does not support the codec used in this video of the page. For demo simplicity we'll link you to the original file, but you may also want to learn how to make videos compatible for all browsers.
surf.mp4
MPEG-4 video – 32 MB
22s · 1280 × 720
":original": {
  "robot": "/upload/handle"
}
🤖/upload/handle
This bot receives uploads that your users throw at you from browser or apps, or that you throw at us programmatically

Step 2: Resize videos to 1280×720 using the fillcrop strategy and encode for WebM (VP9)

We offer a variety of video encoding features like optimizing for different devices, merging, injecting ads, changing audio tracks, or adding company logos. Learn more ›

⚠️ It seems your browser does not support the codec used in this video of the page. For demo simplicity we'll link you to the original file, but you may also want to learn how to make videos compatible for all browsers.
surf-0.webm
WebM video – 8.7 MB
22s · 1280 × 720
"video_resized": {
  "robot": "/video/encode",
  "use": ":original",
  "ffmpeg_stack": "v6.0.0",
  "resize_strategy": "fillcrop",
  "preset": "webm",
  "width": 1280,
  "height": 720,
  "ffmpeg": {
    "b": "3200k",
    "maxrate": "3200k",
    "bufsize": "3200k",
    "bt": "4800k"
  }
}
🤖/video/encode
This bot encodes, resizes, applies watermarks to videos and animated GIFs

Step 3: Take screenshots of webpages or HTML files

We can process your documents in an automated way, saving you costly resources. Learn more ›

⚠️ It seems your browser does not support the codec used in this video of the page. For demo simplicity we'll link you to the original file, but you may also want to learn how to make videos compatible for all browsers.
Image – 29 KB
1280 × 720
"watermark_screenshot": {
  "robot": "/html/convert",
  "format": "png",
  "width": 1280,
  "height": 720,
  "omit_background": true,
  "url": "https://s3.amazonaws.com/demos.transloadit.com/democode/janice.html?logo_url=https%3A%2F%2Fs3.amazonaws.com%2Ftest.transloadit.com%2Fbww_lockup_logo.svg&store_name=Eat%20at%20Joes&label=Today%2030%25%20OFF"
}
🤖/html/convert
This bot takes screenshots of web pages or uploaded HTML pages

Step 4: Watermark videos

⚠️ It seems your browser does not support the codec used in this video of the page. For demo simplicity we'll link you to the original file, but you may also want to learn how to make videos compatible for all browsers.
surf-0.webm
WebM video – 8.7 MB
22s · 1280 × 720
"video_watermarked": {
  "robot": "/video/encode",
  "use": {
    "bundle_steps": true,
    "steps": [
      {
        "name": "video_resized",
        "as": "video"
      },
      {
        "name": "watermark_screenshot",
        "as": "watermark"
      }
    ]
  },
  "ffmpeg_stack": "v6.0.0",
  "watermark_size": "100%",
  "preset": "webm",
  "width": 1280,
  "height": 720,
  "ffmpeg": {
    "b": "3200k",
    "maxrate": "3200k",
    "bufsize": "3200k",
    "bt": "4800k"
  }
}
🤖/video/encode
This bot encodes, resizes, applies watermarks to videos and animated GIFs

Step 5: Export files to Amazon S3

We export to the storage platform of your choice. Learn more ›

:original
video_resized
watermark_screenshot
video_watermarked

Once all files have been exported, we can ping a URL of your choice with the Assembly status JSON.

"exported": {
  "use": [
    ":original",
    "watermark_screenshot",
    "video_resized",
    "video_watermarked"
  ],
  "robot": "/s3/store",
  "credentials": "YOUR_AWS_CREDENTIALS",
  "url_prefix": "https://demos.transloadit.com/"
}
🤖/s3/store
This bot exports encoding results to Amazon S3
Since this is a store Robot, be sure to use Template Credentials so that any sensitive data is encrypted and stored in our database, making sure that they’re never exposed to any end-user.

Live Demo. See for yourself

This live demo is powered by Uppy, our open source file uploader that you can also use without Transloadit, andtus, our open protocol for resumable file uploads that is making uploading more reliable across the world.

Build this in your own language

{
  "steps": {
    ":original": {
      "robot": "/upload/handle"
    },
    "video_resized": {
      "robot": "/video/encode",
      "use": ":original",
      "ffmpeg_stack": "v6.0.0",
      "resize_strategy": "fillcrop",
      "preset": "webm",
      "width": 1280,
      "height": 720,
      "ffmpeg": {
        "b": "3200k",
        "maxrate": "3200k",
        "bufsize": "3200k",
        "bt": "4800k"
      }
    },
    "watermark_screenshot": {
      "robot": "/html/convert",
      "format": "png",
      "width": 1280,
      "height": 720,
      "omit_background": true,
      "url": "https://s3.amazonaws.com/demos.transloadit.com/democode/janice.html?logo_url=https%3A%2F%2Fs3.amazonaws.com%2Ftest.transloadit.com%2Fbww_lockup_logo.svg&store_name=Eat%20at%20Joes&label=Today%2030%25%20OFF"
    },
    "video_watermarked": {
      "robot": "/video/encode",
      "use": {
        "bundle_steps": true,
        "steps": [
          {
            "name": "video_resized",
            "as": "video"
          },
,          {
            "name": "watermark_screenshot",
            "as": "watermark"
          }
        ]
      },
      "ffmpeg_stack": "v6.0.0",
      "watermark_size": "100%",
      "preset": "webm",
      "width": 1280,
      "height": 720,
      "ffmpeg": {
        "b": "3200k",
        "maxrate": "3200k",
        "bufsize": "3200k",
        "bt": "4800k"
      }
    },
    "exported": {
      "use": [":original", "watermark_screenshot", "video_resized", "video_watermarked"],
      "robot": "/s3/store",
      "credentials": "YOUR_AWS_CREDENTIALS",
      "url_prefix": "https://demos.transloadit.com/"
    }
  }
}

# Prerequisites: brew install curl jq || sudo apt install curl jq
# To avoid tampering, use Signature Authentication
echo '{
  "template_id": undefined,
  "auth": {
    "key": "YOUR_TRANSLOADIT_KEY"
  },
  "steps": {
    ":original": {
      "robot": "/upload/handle"
    },
    "video_resized": {
      "robot": "/video/encode",
      "use": ":original",
      "ffmpeg_stack": "v6.0.0",
      "resize_strategy": "fillcrop",
      "preset": "webm",
      "width": 1280,
      "height": 720,
      "ffmpeg": {
        "b": "3200k",
        "maxrate": "3200k",
        "bufsize": "3200k",
        "bt": "4800k"
      }
    },
    "watermark_screenshot": {
      "robot": "/html/convert",
      "format": "png",
      "width": 1280,
      "height": 720,
      "omit_background": true,
      "url": "https://s3.amazonaws.com/demos.transloadit.com/democode/janice.html?logo_url=https%3A%2F%2Fs3.amazonaws.com%2Ftest.transloadit.com%2Fbww_lockup_logo.svg&store_name=Eat%20at%20Joes&label=Today%2030%25%20OFF"
    },
    "video_watermarked": {
      "robot": "/video/encode",
      "use": {
        "bundle_steps": true,
        "steps": [
          {
            "name": "video_resized",
            "as": "video"
          },
,          {
            "name": "watermark_screenshot",
            "as": "watermark"
          }
        ]
      },
      "ffmpeg_stack": "v6.0.0",
      "watermark_size": "100%",
      "preset": "webm",
      "width": 1280,
      "height": 720,
      "ffmpeg": {
        "b": "3200k",
        "maxrate": "3200k",
        "bufsize": "3200k",
        "bt": "4800k"
      }
    },
    "exported": {
      "use": [":original", "watermark_screenshot", "video_resized", "video_watermarked"],
      "robot": "/s3/store",
      "credentials": "YOUR_AWS_CREDENTIALS",
      "url_prefix": "https://demos.transloadit.com/"
    }
  }
}' | curl \\
    --request POST \\
    --form 'params=<-' \\
    --form myfile1=@./surf.mp4 \\
    https://api2.transloadit.com/assemblies | jq

// Install via Swift Package Manager:
// dependencies: [
//   .package(url: "https://github.com/transloadit/TransloaditKit", .upToNextMajor(from: "3.0.0"))
// ]

// Or via CocoaPods:
// pod 'Transloadit', '~> 3.0.0'

// Auth
let credentials = Credentials(key: "YOUR_TRANSLOADIT_KEY")

// Init
let transloadit = Transloadit(credentials: credentials, session: "URLSession.shared")

// Add files to upload
let filesToUpload: [URL] = ...

// Execute
let assembly = transloadit.assembly(steps: [_originalStep, video_resizedStep, watermark_screenshotStep, video_watermarkedStep, exportedStep], andUpload: filesToUpload) { result in
  switch result {
  case .success(let assembly):
    print("Retrieved (assembly)")
  case .failure(let error):
    print("Assembly error (error)")
  }
}.pollAssemblyStatus { result in
  switch result {
  case .success(let assemblyStatus):
    print("Received assemblystatus (assemblyStatus)")
  case .failure(let error):
    print("Caught polling error (error)")
  }

<!-- This pulls Uppy from our CDN -->
<!-- For smaller self-hosted bundles, install Uppy and plugins manually: -->
<!-- npm i --save @uppy/core @uppy/dashboard @uppy/remote-sources @uppy/transloadit ... -->
<link
  href="https://releases.transloadit.com/uppy/v4.3.0/uppy.min.css"
  rel="stylesheet"
/>
<button id="browse">Select Files</button>
<script type="module">
  import {
    Uppy,
    Dashboard,
    ImageEditor,
    RemoteSources,
    Transloadit,
  } from 'https://releases.transloadit.com/uppy/v4.3.0/uppy.min.mjs'
  const uppy = new Uppy()
    .use(Transloadit, {
      waitForEncoding: true,
      alwaysRunAssembly: true,
      assemblyOptions: {
        params: {
          // To avoid tampering, use Signature Authentication:
          // https://transloadit.com/docs/topics/signature-authentication/
          auth: {
            key: 'YOUR_TRANSLOADIT_KEY',
          },
          // It's often better store encoding instructions in your account
          // and use a `template_id` instead of adding these steps inline
          steps: {
            ':original': {
              robot: '/upload/handle',
            },
            video_resized: {
              robot: '/video/encode',
              use: ':original',
              ffmpeg_stack: 'v6.0.0',
              resize_strategy: 'fillcrop',
              preset: 'webm',
              width: 1280,
              height: 720,
              ffmpeg: {
                b: '3200k',
                maxrate: '3200k',
                bufsize: '3200k',
                bt: '4800k',
              },
            },
            watermark_screenshot: {
              robot: '/html/convert',
              format: 'png',
              width: 1280,
              height: 720,
              omit_background: true,
              url: 'https://s3.amazonaws.com/demos.transloadit.com/democode/janice.html?logo_url=https%3A%2F%2Fs3.amazonaws.com%2Ftest.transloadit.com%2Fbww_lockup_logo.svg&store_name=Eat%20at%20Joes&label=Today%2030%25%20OFF',
            },
            video_watermarked: {
              robot: '/video/encode',
              use: {
                bundle_steps: true,
                steps: [
                  {
                    name: 'video_resized',
                    as: 'video',
                  },
,                  {
                    name: 'watermark_screenshot',
                    as: 'watermark',
                  },
                ],
              },
              ffmpeg_stack: 'v6.0.0',
              watermark_size: '100%',
              preset: 'webm',
              width: 1280,
              height: 720,
              ffmpeg: {
                b: '3200k',
                maxrate: '3200k',
                bufsize: '3200k',
                bt: '4800k',
              },
            },
            exported: {
              use: [':original', 'watermark_screenshot', 'video_resized', 'video_watermarked'],
              robot: '/s3/store',
              credentials: 'YOUR_AWS_CREDENTIALS',
              url_prefix: 'https://demos.transloadit.com/',
            },
          },
        },
      },
    })
    .use(Dashboard, { trigger: '#browse' })
    .use(ImageEditor, { target: Dashboard })
    .use(RemoteSources, {
      companionUrl: 'https://api2.transloadit.com/companion',
    })
    .on('complete', ({ transloadit }) => {
      // Due to `waitForEncoding:true` this is fired after encoding is done.
      // Alternatively, set `waitForEncoding` to `false` and provide a `notify_url`
      console.log(transloadit) // Array of Assembly Statuses
      transloadit.forEach((assembly) => {
        console.log(assembly.results) // Array of all encoding results
      })
    })
    .on('error', (error) => {
      console.error(error)
    })
</script>

// yarn add transloadit || npm i transloadit

// Import
const Transloadit = require('transloadit')

const main = async () => {
  // Init
  const transloadit = new Transloadit({
    authKey: 'YOUR_TRANSLOADIT_KEY',
    authSecret: 'MY_TRANSLOADIT_SECRET',
  })

  // Set Encoding Instructions
  const options = {
    files: {
      myfile_1: './surf.mp4',
    },
    params: {
      steps: {
        ':original': {
          robot: '/upload/handle',
        },
        video_resized: {
          robot: '/video/encode',
          use: ':original',
          ffmpeg_stack: 'v6.0.0',
          resize_strategy: 'fillcrop',
          preset: 'webm',
          width: 1280,
          height: 720,
          ffmpeg: {
            b: '3200k',
            maxrate: '3200k',
            bufsize: '3200k',
            bt: '4800k',
          },
        },
        watermark_screenshot: {
          robot: '/html/convert',
          format: 'png',
          width: 1280,
          height: 720,
          omit_background: true,
          url: 'https://s3.amazonaws.com/demos.transloadit.com/democode/janice.html?logo_url=https%3A%2F%2Fs3.amazonaws.com%2Ftest.transloadit.com%2Fbww_lockup_logo.svg&store_name=Eat%20at%20Joes&label=Today%2030%25%20OFF',
        },
        video_watermarked: {
          robot: '/video/encode',
          use: {
            bundle_steps: true,
            steps: [
              {
                name: 'video_resized',
                as: 'video',
              },
,              {
                name: 'watermark_screenshot',
                as: 'watermark',
              },
            ],
          },
          ffmpeg_stack: 'v6.0.0',
          watermark_size: '100%',
          preset: 'webm',
          width: 1280,
          height: 720,
          ffmpeg: {
            b: '3200k',
            maxrate: '3200k',
            bufsize: '3200k',
            bt: '4800k',
          },
        },
        exported: {
          use: [':original', 'watermark_screenshot', 'video_resized', 'video_watermarked'],
          robot: '/s3/store',
          credentials: 'YOUR_AWS_CREDENTIALS',
          url_prefix: 'https://demos.transloadit.com/',
        },
      },
    },
  }

  // Execute
  const result = await transloadit.createAssembly(options)

  // Show results
  console.log({ result })
}

main().catch(console.error)

# [sudo] npm install transloadify -g

# Auth
export TRANSLOADIT_KEY="YOUR_TRANSLOADIT_KEY"

# Save Encoding Instructions
echo '{
  "steps": {
    ":original": {
      "robot": "/upload/handle"
    },
    "video_resized": {
      "robot": "/video/encode",
      "use": ":original",
      "ffmpeg_stack": "v6.0.0",
      "resize_strategy": "fillcrop",
      "preset": "webm",
      "width": 1280,
      "height": 720,
      "ffmpeg": {
        "b": "3200k",
        "maxrate": "3200k",
        "bufsize": "3200k",
        "bt": "4800k"
      }
    },
    "watermark_screenshot": {
      "robot": "/html/convert",
      "format": "png",
      "width": 1280,
      "height": 720,
      "omit_background": true,
      "url": "https://s3.amazonaws.com/demos.transloadit.com/democode/janice.html?logo_url=https%3A%2F%2Fs3.amazonaws.com%2Ftest.transloadit.com%2Fbww_lockup_logo.svg&store_name=Eat%20at%20Joes&label=Today%2030%25%20OFF"
    },
    "video_watermarked": {
      "robot": "/video/encode",
      "use": {
        "bundle_steps": true,
        "steps": [
          {
            "name": "video_resized",
            "as": "video"
          },
,          {
            "name": "watermark_screenshot",
            "as": "watermark"
          }
        ]
      },
      "ffmpeg_stack": "v6.0.0",
      "watermark_size": "100%",
      "preset": "webm",
      "width": 1280,
      "height": 720,
      "ffmpeg": {
        "b": "3200k",
        "maxrate": "3200k",
        "bufsize": "3200k",
        "bt": "4800k"
      }
    },
    "exported": {
      "use": [":original", "watermark_screenshot", "video_resized", "video_watermarked"],
      "robot": "/s3/store",
      "credentials": "YOUR_AWS_CREDENTIALS",
      "url_prefix": "https://demos.transloadit.com/"
    }
  }
}' > ./steps.json

# Execute
transloadify \
  --input "surf.mp4" \
  --steps "./steps.json" \
  --output "./output.example"

// composer require transloadit/php-sdk
use transloadit\Transloadit;

$transloadit = new Transloadit([
  "key" => "YOUR_TRANSLOADIT_KEY",
  "secret" => "MY_TRANSLOADIT_SECRET",
]);

// Start the Assembly
$response = $transloadit->createAssembly([
  "files" => ["surf.mp4"],
  "params" => [
    "steps" => [
      ":original" => [
        "robot" => "/upload/handle",
      ],
      "video_resized" => [
        "robot" => "/video/encode",
        "use" => ":original",
        "ffmpeg_stack" => "v6.0.0",
        "resize_strategy" => "fillcrop",
        "preset" => "webm",
        "width" => 1280,
        "height" => 720,
        "ffmpeg" => [
          "b" => "3200k",
          "maxrate" => "3200k",
          "bufsize" => "3200k",
          "bt" => "4800k",
        ],
      ],
      "watermark_screenshot" => [
        "robot" => "/html/convert",
        "format" => "png",
        "width" => 1280,
        "height" => 720,
        "omit_background" => true,
        "url" => "https://s3.amazonaws.com/demos.transloadit.com/democode/janice.html?logo_url=https%3A%2F%2Fs3.amazonaws.com%2Ftest.transloadit.com%2Fbww_lockup_logo.svg&store_name=Eat%20at%20Joes&label=Today%2030%25%20OFF",
      ],
      "video_watermarked" => [
        "robot" => "/video/encode",
        "use" => [
          "bundle_steps" => true,
          "steps" => [
            [
              "name" => "video_resized",
              "as" => "video",
            ],
,            [
              "name" => "watermark_screenshot",
              "as" => "watermark",
            ],
          ],
        ],
        "ffmpeg_stack" => "v6.0.0",
        "watermark_size" => "100%",
        "preset" => "webm",
        "width" => 1280,
        "height" => 720,
        "ffmpeg" => [
          "b" => "3200k",
          "maxrate" => "3200k",
          "bufsize" => "3200k",
          "bt" => "4800k",
        ],
      ],
      "exported" => [
        "use" => [":original", "watermark_screenshot", "video_resized", "video_watermarked"],
        "robot" => "/s3/store",
        "credentials" => "YOUR_AWS_CREDENTIALS",
        "url_prefix" => "https://demos.transloadit.com/",
      ],
    ],
  ],
]);

# gem install transloadit

# $ irb -rubygems
# >> require 'transloadit'
# => true

transloadit = Transloadit.new([
  :key => "YOUR_TRANSLOADIT_KEY",
])

# Set Encoding Instructions
_original = transloadit.step(":original", "/upload/handle", {})

video_resized = transloadit.step("video_resized", "/video/encode", [
  :use => ":original",
  :ffmpeg_stack => "v6.0.0",
  :resize_strategy => "fillcrop",
  :preset => "webm",
  :width => 1280,
  :height => 720,
  :ffmpeg => [
    :b => "3200k",
    :maxrate => "3200k",
    :bufsize => "3200k",
    :bt => "4800k"
  ]
])

watermark_screenshot = transloadit.step("watermark_screenshot", "/html/convert", [
  :format => "png",
  :width => 1280,
  :height => 720,
  :omit_background => true,
  :url => "https://s3.amazonaws.com/demos.transloadit.com/democode/janice.html?logo_url=https%3A%2F%2Fs3.amazonaws.com%2Ftest.transloadit.com%2Fbww_lockup_logo.svg&store_name=Eat%20at%20Joes&label=Today%2030%25%20OFF"
])

video_watermarked = transloadit.step("video_watermarked", "/video/encode", [
  :use => [
    :bundle_steps => true,
    :steps => [
      [
        :name => "video_resized",
        :as => "video"
      ],
,      [
        :name => "watermark_screenshot",
        :as => "watermark"
      ]
    ]
  ],
  :ffmpeg_stack => "v6.0.0",
  :watermark_size => "100%",
  :preset => "webm",
  :width => 1280,
  :height => 720,
  :ffmpeg => [
    :b => "3200k",
    :maxrate => "3200k",
    :bufsize => "3200k",
    :bt => "4800k"
  ]
])

exported = transloadit.step("exported", "/s3/store", [
  :use => [":original", "watermark_screenshot", "video_resized", "video_watermarked"],
  :credentials => "YOUR_AWS_CREDENTIALS",
  :url_prefix => "https://demos.transloadit.com/"
])

transloadit.assembly([
  :steps => [_original, video_resized, watermark_screenshot, video_watermarked, exported]
])

# Add files to upload
files = []
files.push("surf.mp4")

# Start the Assembly
response = assembly.create! *files

until response.finished?
  sleep 1; response.reload!
end

if !response.error?
  # handle success
end

# pip install pytransloadit
from transloadit import client

tl = client.Transloadit('YOUR_TRANSLOADIT_KEY', 'MY_TRANSLOADIT_SECRET')
assembly = tl.new_assembly()

# Set Encoding Instructions
assembly.add_step(":original", "/upload/handle", {})

assembly.add_step("video_resized", "/video/encode", {
  'use': ':original',
  'ffmpeg_stack': 'v6.0.0',
  'resize_strategy': 'fillcrop',
  'preset': 'webm',
  'width': 1280,
  'height': 720,
  'ffmpeg': {
    'b': '3200k',
    'maxrate': '3200k',
    'bufsize': '3200k',
    'bt': '4800k'
  }
})

assembly.add_step("watermark_screenshot", "/html/convert", {
  'format': 'png',
  'width': 1280,
  'height': 720,
  'omit_background': True,
  'url': 'https://s3.amazonaws.com/demos.transloadit.com/democode/janice.html?logo_url=https%3A%2F%2Fs3.amazonaws.com%2Ftest.transloadit.com%2Fbww_lockup_logo.svg&store_name=Eat%20at%20Joes&label=Today%2030%25%20OFF'
})

assembly.add_step("video_watermarked", "/video/encode", {
  'use': {
    'bundle_steps': True,
    'steps': [
      {
        'name': 'video_resized',
        'as': 'video'
      },
,      {
        'name': 'watermark_screenshot',
        'as': 'watermark'
      }
    ]
  },
  'ffmpeg_stack': 'v6.0.0',
  'watermark_size': '100%',
  'preset': 'webm',
  'width': 1280,
  'height': 720,
  'ffmpeg': {
    'b': '3200k',
    'maxrate': '3200k',
    'bufsize': '3200k',
    'bt': '4800k'
  }
})

assembly.add_step("exported", "/s3/store", {
  'use': [':original', 'watermark_screenshot', 'video_resized', 'video_watermarked'],
  'credentials': 'YOUR_AWS_CREDENTIALS',
  'url_prefix': 'https://demos.transloadit.com/'
})

# Add files to upload
assembly.add_file(open('surf.mp4', 'rb'))

# Start the Assembly
assembly_response = assembly.create(retries=5, wait=True)

print(assembly_response.data.get('assembly_ssl_url'))
# or:
print(assembly_response.data['assembly_ssl_url'])

// go get gopkg.in/transloadit/go-sdk.v1
package main

import (
  "context"
  "fmt"
  "github.com/transloadit/go-sdk"
)

func main() {
  // Create client
  options := transloadit.DefaultConfig
  options.AuthKey = "YOUR_TRANSLOADIT_KEY"
  options.AuthSecret = "MY_TRANSLOADIT_SECRET"
  client := transloadit.NewClient(options)

  // Initialize new Assembly
  assembly := transloadit.NewAssembly()

  // Set Encoding Instructions
  assembly.AddStep(":original", map[string]interface{}{
    "robot": "/upload/handle",
  })

  assembly.AddStep("video_resized", map[string]interface{}{
    "robot": "/video/encode",
    "use": ":original",
    "ffmpeg_stack": "v6.0.0",
    "resize_strategy": "fillcrop",
    "preset": "webm",
    "width": 1280,
    "height": 720,
    "ffmpeg": map[string]interface{}{
      "b": "3200k",
      "maxrate": "3200k",
      "bufsize": "3200k",
      "bt": "4800k",
    },
  })

  assembly.AddStep("watermark_screenshot", map[string]interface{}{
    "robot": "/html/convert",
    "format": "png",
    "width": 1280,
    "height": 720,
    "omit_background": true,
    "url": "https://s3.amazonaws.com/demos.transloadit.com/democode/janice.html?logo_url=https%3A%2F%2Fs3.amazonaws.com%2Ftest.transloadit.com%2Fbww_lockup_logo.svg&store_name=Eat%20at%20Joes&label=Today%2030%25%20OFF",
  })

  assembly.AddStep("video_watermarked", map[string]interface{}{
    "robot": "/video/encode",
    "use": map[string]interface{}{
      "bundle_steps": true,
      "steps": [
        map[string]interface{}{
          "name": "video_resized",
          "as": "video",
        },
  ,      map[string]interface{}{
          "name": "watermark_screenshot",
          "as": "watermark",
        },
      ],
    },
    "ffmpeg_stack": "v6.0.0",
    "watermark_size": "100%",
    "preset": "webm",
    "width": 1280,
    "height": 720,
    "ffmpeg": map[string]interface{}{
      "b": "3200k",
      "maxrate": "3200k",
      "bufsize": "3200k",
      "bt": "4800k",
    },
  })

  assembly.AddStep("exported", map[string]interface{}{
    "use": [":original", "watermark_screenshot", "video_resized", "video_watermarked"],
    "robot": "/s3/store",
    "credentials": "YOUR_AWS_CREDENTIALS",
    "url_prefix": "https://demos.transloadit.com/",
  })

  // Add files to upload
  assembly.AddFile("surf.mp4"))

  // Start the Assembly
  info, err := client.StartAssembly(context.Background(), assembly)
  if err != nil {
    panic(err)
  }

  // All files have now been uploaded and the Assembly has started but no
  // results are available yet since the conversion has not finished.
  // WaitForAssembly provides functionality for polling until the Assembly
  // has ended.
  info, err = client.WaitForAssembly(context.Background(), info)
  if err != nil {
    panic(err)
  }

  fmt.Printf("You can check some results at: ")
  fmt.Printf("  - %s\n", info.Results[":original"][0].SSLURL)
  fmt.Printf("  - %s\n", info.Results["video_resized"][0].SSLURL)
  fmt.Printf("  - %s\n", info.Results["watermark_screenshot"][0].SSLURL)
  fmt.Printf("  - %s\n", info.Results["video_watermarked"][0].SSLURL)
  fmt.Printf("  - %s\n", info.Results["exported"][0].SSLURL)
}

// implementation 'com.transloadit.sdk:transloadit:1.0.0'

import com.transloadit.sdk.Assembly;
import com.transloadit.sdk.Transloadit;
import com.transloadit.sdk.exceptions.LocalOperationException;
import com.transloadit.sdk.exceptions.RequestException;
import com.transloadit.sdk.response.AssemblyResponse;
import java.io.File;
import java.util.HashMap;
import java.util.Map;

public class Main {
  public static void main(String[] args) {
    // Initialize the Transloadit client
    Transloadit transloadit = new Transloadit("YOUR_TRANSLOADIT_KEY", "MY_TRANSLOADIT_SECRET");

    Assembly assembly = transloadit.newAssembly();

    // Set Encoding Instructions
    Map<String, Object> _originalStepOptions = new HashMap();
    assembly.addStep(":original", "/upload/handle", _originalStepOptions);

    Map<String, Object> video_resizedStepOptions = new HashMap();
    video_resizedStepOptions.put("use", ":original");
    video_resizedStepOptions.put("ffmpeg_stack", "v6.0.0");
    video_resizedStepOptions.put("resize_strategy", "fillcrop");
    video_resizedStepOptions.put("preset", "webm");
    video_resizedStepOptions.put("width", 1280);
    video_resizedStepOptions.put("height", 720);
    video_resizedStepOptions.put("ffmpeg", {
        "b": "3200k",
        "maxrate": "3200k",
        "bufsize": "3200k",
        "bt": "4800k",
      });
    assembly.addStep("video_resized", "/video/encode", video_resizedStepOptions);

    Map<String, Object> watermark_screenshotStepOptions = new HashMap();
    watermark_screenshotStepOptions.put("format", "png");
    watermark_screenshotStepOptions.put("width", 1280);
    watermark_screenshotStepOptions.put("height", 720);
    watermark_screenshotStepOptions.put("omit_background", true);
    watermark_screenshotStepOptions.put("url", "https://s3.amazonaws.com/demos.transloadit.com/democode/janice.html?logo_url=https%3A%2F%2Fs3.amazonaws.com%2Ftest.transloadit.com%2Fbww_lockup_logo.svg&store_name=Eat%20at%20Joes&label=Today%2030%25%20OFF");
    assembly.addStep("watermark_screenshot", "/html/convert", watermark_screenshotStepOptions);

    Map<String, Object> video_watermarkedStepOptions = new HashMap();
    video_watermarkedStepOptions.put("use", {
        "bundle_steps": true,
        "steps": new String[] { {
          "name": "video_resized",
          "as": "video",
        }, {
          "name": "watermark_screenshot",
          "as": "watermark",
        } },
      });
    video_watermarkedStepOptions.put("ffmpeg_stack", "v6.0.0");
    video_watermarkedStepOptions.put("watermark_size", "100%");
    video_watermarkedStepOptions.put("preset", "webm");
    video_watermarkedStepOptions.put("width", 1280);
    video_watermarkedStepOptions.put("height", 720);
    video_watermarkedStepOptions.put("ffmpeg", {
        "b": "3200k",
        "maxrate": "3200k",
        "bufsize": "3200k",
        "bt": "4800k",
      });
    assembly.addStep("video_watermarked", "/video/encode", video_watermarkedStepOptions);

    Map<String, Object> exportedStepOptions = new HashMap();
    exportedStepOptions.put("use", new String[] { ":original", "watermark_screenshot", "video_resized", "video_watermarked" });
    exportedStepOptions.put("credentials", "YOUR_AWS_CREDENTIALS");
    exportedStepOptions.put("url_prefix", "https://demos.transloadit.com/");
    assembly.addStep("exported", "/s3/store", exportedStepOptions);

    // Add files to upload
    assembly.addFile(new File("surf.mp4"));

    // Start the Assembly
    try {
      AssemblyResponse response = assembly.save();

      // Wait for Assembly to finish executing
      while (!response.isFinished()) {
        response = transloadit.getAssemblyByUrl(response.getSslUrl());
      }

      System.out.println(response.getId());
      System.out.println(response.getUrl());
      System.out.println(response.json());
    } catch (RequestException | LocalOperationException e) {
      // Handle exception here
    }
  }
}

So many ways to integrate

Transloadit is a service for companies with developers. As a developer, there are many ways you can put us to good use.

  • Bulk imports

    Add one of our import Robots to acquire and transcode massive media libraries.

  • Handling uploads

    We are the experts at reliably handling uploads. We wrote the protocol for it.

  • Front-end integration

    We integrate with web browsers via our next-gen file uploader Uppy and SDKs for Android and iOS.

  • Back-end integration

    Send us batch jobs in any server language using one of our SDKs or directly interfacing with our REST API.

  • Pingbacks

    Configure a notify_url to let your server receive transcoding results JSON in the transloadit POST field.

Other cool demos

Ready to integrate?

Try out Transloadit’s powerful features and see the difference for yourself. Start with no strings attached, and upgrade whenever youʼre ready.

Sign up Book a Demo
No credit card needed · 5 GB included in the free plan
Cancel anytime
