Export files to Microsoft Azure

🤖/azure/store exports encoding results to Microsoft Azure.

Usage example

{
  "steps": {
    "exported": {
      "robot": "/azure/store",
      "use": ":original",
      "credentials": "YOUR_AZURE_CREDENTIALS",
      "path": "my_target_folder/${unique_prefix}/${file.url_name}"
    }
  }
}

Parameters

• interpolate

  boolean | Record<string, boolean>

  Controls whether Assembly Variables are interpolated for individual instruction fields.

  By default, most Robot instruction fields interpolate Assembly Variables. Set this to false to treat every instruction field as literal text, or set an individual field path to false to treat only that field as literal text. For Robot-specific fields that are literal by default, set this to true or set that field path to true to opt back into interpolation.

  Use field names such as path, or dotted paths such as ffmpeg.vf for nested objects.

• output_meta

  Record<string, boolean> | boolean | Array<string>

  Allows you to specify a set of metadata that is more expensive on CPU power to calculate, and thus is disabled by default to keep your Assemblies processing fast.

  For images, you can add "has_transparency": true in this object to extract if the image contains transparent parts and "dominant_colors": true to extract an array of hexadecimal color codes from the image.

  For images, you can also add "blurhash": true to extract a BlurHash⁠ string — a compact representation of a placeholder for the image, useful for showing a blurred preview while the full image loads.

  For videos, you can add the "colorspace": true parameter to extract the colorspace of the output video.

  For videos, you can also add "interlaced": true to detect whether the video is interlaced. This combines the cheap ffprobe field_order flag with a bounded idet sampling pass over the first frames of the source, exposing interlaced, field_order, and a diagnostic interlace_detection object under file.meta. This is computationally expensive and billed accordingly.

  For audio, you can add "mean_volume": true to get a single value representing the mean average volume of the audio file.

  You can also set this to false to skip metadata extraction and speed up transcoding.

• user_meta

  Record<string, any>(default: {})

  Adds custom JSON metadata to each emitted file without changing its contents. Nested objects and arrays are supported.

  Inheritance depends on the Robot. Values merge with existing user_meta on the output file; the current Step replaces matching top-level keys. Assign required keys explicitly when a Robot creates fresh outputs.

  In processing Steps, ${file.*} refers to the first input and ${result.*} to the emitted file. Values are evaluated per output after the Robot runs, before subsequent metadata extraction and temporary storage. On :original, values are evaluated per upload before metadata extraction.

  Downstream Steps read ${file.user_meta.key}. See Custom metadata for a complete example and inheritance rules.

• result

  boolean(default: false)

  Whether the results of this Step should be present in the Assembly Status JSON

• queue

  batch

  Setting the queue to 'batch', manually downgrades the priority of jobs for this step to avoid consuming Priority job slots for jobs that don't need zero queue waiting times

• force_accept

  boolean(default: false)

  Force a Robot to accept a file type it would have ignored.

  By default, Robots ignore files they are not familiar with. 🤖/video/encode, for example, will happily ignore input images.

  With the force_accept parameter set to true, you can force Robots to accept all files thrown at them. This will typically lead to errors and should only be used for debugging or combatting edge cases.

• ignore_errors

  boolean | Array<meta | execute>(default: [])

  Ignore errors during specific phases of processing.

  Setting this to ["meta"] will cause the Robot to ignore errors during metadata extraction.

  Setting this to ["execute"] will cause the Robot to ignore errors during the main execution phase.

  Setting this to true is equivalent to ["meta", "execute"] and will ignore errors in both phases.

• use

  string | Array<string> | Array<object> | object

  Specifies which Step(s) to use as input.

  • You can pick any names for Steps except ":original" (reserved for user uploads handled by Transloadit)
  • You can provide several Steps as input with arrays:

    {
      "use": [
        ":original",
        "encoded",
        "resized"
      ]
    }


  • You can also tag input Steps with as to pass semantic intent to robots:

    {
      "use": [
        {
          "name": ":original",
          "as": "image"
        },
        {
          "name": ":original",
          "as": "mask"
        }
      ]
    }


  Tip

  That's likely all you need to know about use, but you can view Advanced use cases.

• credentials

  string

  Please create your associated Template Credentials in your Transloadit account and use the name of your Template Credentials as this parameter's value. They will contain the values for your Azure Container, Account and Key.

  While we recommend to use Template Credentials at all times, some use cases demand dynamic credentials for which using Template Credentials is too unwieldy because of their static nature. If you have this requirement, feel free to use the following parameters instead: "account", "key", "container".

• path

  string(default: "${unique_prefix}/${file.url_name}")

  The path at which the file is to be stored. This may include any available Assembly variables.

• content_type

  string

  The content type with which to store the file. By default this will be guessed by Azure.

• content_encoding

  string

  The content encoding with which to store the file. By default this will be guessed by Azure.

• content_language

  string

  The content language with which to store the file. By default this will be guessed by Azure.

• content_disposition

  string

  The content disposition with which to store the file. By default this will be guessed by Azure.

• cache_control

  string

  The cache control header with which to store the file.

• metadata

  Record<string, string | number | boolean>(default: {})

  A JavaScript object containing a list of metadata to be set for this file on Azure, such as { FileURL: "${file.url_name}" }. This can also include any available Assembly variables.

• sas_expires_in

  string | number

  Set this to a number to enable shared access signatures for your stored object. This reflects the number of seconds that the signature will be valid for once the object is stored. Enabling this will attach the shared access signature (SAS) to the result URL of your object.

• sas_permissions

  string

  Set this to a combination of r (read), w (write) and d (delete) for your shared access signatures (SAS) permissions.
