Convert documents into different formats

🤖/document/convert converts documents into different formats.

Sometimes, a certain file type might not support what you are trying to accomplish. Perhaps your company is trying to automate document formatting, but it only works with docx, so all your docs need to be converted. Or maybe your stored jpg files are taking up too much space and you want a lighter format. Whatever the case, we have you covered.

Using this Robot, you can bypass the issues that certain file types may bring, by converting your file into the most suitable format. This also works in conjunction with our other Robots, allowing for even greater versatility when using our services.

The following file formats can be converted from:

  • ai
  • csv
  • doc
  • docx
  • eps
  • gif
  • html
  • jpg
  • latex
  • md
  • oda
  • odd
  • odt
  • ott
  • png
  • pot
  • pps
  • ppt
  • pptx
  • ppz
  • ps
  • rtf
  • rtx
  • srt
  • svg
  • text
  • txt
  • vtt
  • xhtml
  • xla
  • xls
  • xlsx
  • xml

Usage example

Convert uploaded files to PDF documents:

{
  "steps": {
    "converted": {
      "robot": "/document/convert",
      "use": ":original",
      "format": "pdf"
    }
  }
}

Parameters

  • interpolate

    boolean | Record<string, boolean>

    Controls whether Assembly Variables are interpolated for individual instruction fields.

    By default, most Robot instruction fields interpolate Assembly Variables. Set this to false to treat every instruction field as literal text, or set an individual field path to false to treat only that field as literal text. For Robot-specific fields that are literal by default, set this to true or set that field path to true to opt back into interpolation.

    Use field names such as path, or dotted paths such as ffmpeg.vf for nested objects.

  • output_meta

    Record<string, boolean> | boolean | Array<string>

    Allows you to specify a set of metadata that is more expensive on CPU power to calculate, and thus is disabled by default to keep your Assemblies processing fast.

    For images, you can add "has_transparency": true in this object to extract if the image contains transparent parts and "dominant_colors": true to extract an array of hexadecimal color codes from the image.

    For images, you can also add "blurhash": true to extract a BlurHash string — a compact representation of a placeholder for the image, useful for showing a blurred preview while the full image loads.

    For videos, you can add the "colorspace: true" parameter to extract the colorspace of the output video.

    For audio, you can add "mean_volume": true to get a single value representing the mean average volume of the audio file.

    You can also set this to false to skip metadata extraction and speed up transcoding.

  • result

    boolean (default: false)

    Whether the results of this Step should be present in the Assembly Status JSON

  • queue

    batch

    Setting the queue to 'batch', manually downgrades the priority of jobs for this step to avoid consuming Priority job slots for jobs that don't need zero queue waiting times

  • force_accept

    boolean (default: false)

    Force a Robot to accept a file type it would have ignored.

    By default, Robots ignore files they are not familiar with. 🤖/video/encode, for example, will happily ignore input images.

    With the force_accept parameter set to true, you can force Robots to accept all files thrown at them. This will typically lead to errors and should only be used for debugging or combatting edge cases.

  • ignore_errors

    boolean | Array<meta | execute> (default: [])

    Ignore errors during specific phases of processing.

    Setting this to ["meta"] will cause the Robot to ignore errors during metadata extraction.

    Setting this to ["execute"] will cause the Robot to ignore errors during the main execution phase.

    Setting this to true is equivalent to ["meta", "execute"] and will ignore errors in both phases.

  • use

    string | Array<string> | Array<object> | object

    Specifies which Step(s) to use as input.

    • You can pick any names for Steps except ":original" (reserved for user uploads handled by Transloadit)
    • You can provide several Steps as input with arrays:
      {
  "use": [
    ":original",
    "encoded",
    "resized"
  ]
}
    • You can also tag an input Step with as to pass semantic intent to robots:
    • You can also tag input Steps with as to pass semantic intent to robots:
      {
  "use": [
    {
      "name": ":original",
      "as": "image"
    },
    {
      "name": ":original",
      "as": "mask"
    }
  ]
}

  • format — required

    ai | csv | doc | docx | eps | gif | html |

    The desired format for document conversion.

  • markdown_format

    commonmark | gfm (default: "gfm")

    Markdown can be represented in several variants, so when using this Robot to transform Markdown into HTML please specify which revision is being used.

  • markdown_theme

    bare | github (default: "github")

    This parameter overhauls your Markdown files styling based on several canned presets.

  • pdf_margin

    string (default: "6.25mm,6.25mm,14.11mm,6.25mm")

    PDF Paper margins, separated by , and with units.

    We support the following unit values: px, in, cm, mm.

    Currently this parameter is only supported when converting from html.

  • pdf_print_background

    boolean (default: true)

    Print PDF background graphics.

    Currently this parameter is only supported when converting from html.

  • pdf_format

    A0 | A1 | A2 | A3 | A4 | A5 | A6 | (default: "Letter")

    PDF paper format.

    Currently this parameter is only supported when converting from html.

  • pdf_display_header_footer

    boolean (default: false)

    Display PDF header and footer.

    Currently this parameter is only supported when converting from html.

  • pdf_header_template

    string

    HTML template for the PDF print header.

    Should be valid HTML markup with following classes used to inject printing values into them:

    • date formatted print date
    • title document title
    • url document location
    • pageNumber current page number
    • totalPages total pages in the document

    Currently this parameter is only supported when converting from html, and requires pdf_display_header_footer to be enabled.

    To change the formatting of the HTML element, the font-size must be specified in a wrapper. For example, to center the page number at the top of a page you'd use the following HTML for the header template:

    <div style="font-size: 15px; width: 100%; text-align: center;"><span class="pageNumber"></span></div>

  • pdf_footer_template

    string

    HTML template for the PDF print footer.

    Should use the same format as the pdf_header_template.

    Currently this parameter is only supported when converting from html, and requires pdf_display_header_footer to be enabled.

    To change the formatting of the HTML element, the font-size must be specified in a wrapper. For example, to center the page number in the footer you'd use the following HTML for the footer template:

    <div style="font-size: 15px; width: 100%; text-align: center;"><span class="pageNumber"></span></div>
